Subject Topic: fuse blowing Post Reply Post New Topic
PersonSigone89
via mobile 09/5/2022 at 5:37pm
 Location:
 Outfit: None Entered View Sigone89's Profile View Profile   Reply to Sigone89 Reply   Quote Sigone89 Quote
Joined: 09/5/2022

Standard Member
Standard Member

Forum Posts:   5
Site Reviews Total: 0
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 0
Site Reviews 2021: 0
Site Reviews 2020: 0
Site Reviews 2019: 0
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 0
Site Nights 2021: 0
Site Nights 2020: 0
Site Nights 2019: 0
Site Nights 2018: 0
I have a 2001 Toyota Hiace and the battery 40 amp fuse (orange in pic) keeps blowing. I don't know why.

Also, after looking at some diagrams online, is the other 40amp fuse in the wrong place? Should it be where is coloured yellow?




PersonSoggySteve
02/6/2022 at 10:26am
 Location: Bristol Uk
 Outfit: 2012 Outwell Trout Lake 4 & Tarp View SoggySteve's Profile View Profile   Reply to SoggySteve Reply   Quote SoggySteve Quote
Joined: 06/6/2012

Gold Member
Gold Member

Forum Posts:   434
Tent Reviews:   1
Site Reviews Total: 6
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 2
Site Reviews 2021: 0
Site Reviews 2020: 0
Site Reviews 2019: 3
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 7
Site Nights 2021: 0
Site Nights 2020: 0
Site Nights 2019: 12
Site Nights 2018: 0
The most likely cause is that your split charging system is allowing a huge amount of current flow to a leisure battery when it needs a decent charge. Split relays I believe are more often than not purely voltage sensing to work out when to open the taps from the main battery to the auxiliary battery which in turn has no opinion on what the charge current limit is on your leisure battery or its state of charge.

If you imagine your poor leisure battery would ideally like different current and voltage depending on its state of discharge then split chargers just don't consider this at all. Take my advice and install an intelligent DC to DC charger and then set the charger for the leisure battery type that you have and be done with it. You already have the wiring in place so it should be easy.

We use the Victron Orion bluetooth one that supplies 30amps and actually smart charges the battery as you drive. They are around £200 but you can get cheaper ones though I personally have no recommendations on those. We have a 60amp fuse in-between this and the battery itself and as well as another between the alternator and the DC DC charger.

If it is fact not the reason that you are blowing fuses then at least you are now charging your batteries properly..


Campervan and Motorhome Insurance - Special Discount for UKCampsite.co.uk members
Caravan Guard Special Discount for UKCampsite.co.uk members on Campervan and Motorhome Insurance. Get 5 star rated cover and big savings - for a quote simply click Online Quotation

PersonErnie DB
05/6/2022 at 6:03pm
 Location:
 Outfit:  View Ernie DB's Profile View Profile   Reply to Ernie DB Reply   Quote Ernie DB Quote
Joined: 29/7/2011

Silver Member
Silver Member

Forum Posts:   118
Tent Reviews:   1
Site Reviews Total: 0
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 0
Site Reviews 2021: 0
Site Reviews 2020: 0
Site Reviews 2019: 0
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 0
Site Nights 2021: 0
Site Nights 2020: 0
Site Nights 2019: 0
Site Nights 2018: 0
Quote: Originally posted by SoggySteve on 02/6/2022
The most likely cause is that your split charging system is allowing a huge amount of current flow to a leisure battery when it needs a decent charge


Would you care to put a value on this huge amount of current, assuming it
is a 'wet' lead acid battery in good condition?

-------------
Never argue with fools........They drag you down to their level, then beat you with experience.


PersonSoggySteve
18/6/2022 at 11:13am
 Location: Bristol Uk
 Outfit: 2012 Outwell Trout Lake 4 & Tarp View SoggySteve's Profile View Profile   Reply to SoggySteve Reply   Quote SoggySteve Quote
Joined: 06/6/2012

Gold Member
Gold Member

Forum Posts:   434
Tent Reviews:   1
Site Reviews Total: 6
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 2
Site Reviews 2021: 0
Site Reviews 2020: 0
Site Reviews 2019: 3
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 7
Site Nights 2021: 0
Site Nights 2020: 0
Site Nights 2019: 12
Site Nights 2018: 0
Quote:

Would you care to put a value on this huge amount of current, assuming it
is a 'wet' lead acid battery in good condition?


Not really. I have never clamp metered the leisure battery feed from a split charger at different states of charge. A typical alternator will provide maybe 100amps at high revs though I'm not saying that a battery will accept such a high current all the time any more than the vehicle battery.

I think my main point is that having a DC to DC charger will not under current the battery and will provide the correct voltage and current based on the battery technology such as wet LA being AGM or even Lithium at a given state of charge. You probably know that AGM needs the high voltage which a standard alternator usually cannot provide. Split chargers are not like diodes either so the current can flow both ways depending on the voltage of either cell.


Personfleck2
via mobile 29/6/2022 at 7:03am
 Location: Derbyshire
 Outfit: Elddis accordo Motorhome View fleck2's Profile View Profile   Reply to fleck2 Reply   Quote fleck2 Quote
Joined: 27/4/2006

Platinum Member
Platinum Member

Forum Posts:   1168
Site Reviews Total: 8
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 0
Site Reviews 2021: 0
Site Reviews 2020: 0
Site Reviews 2019: 0
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 0
Site Nights 2021: 0
Site Nights 2020: 0
Site Nights 2019: 0
Site Nights 2018: 0
If the relay is stuck the starter motor will probably blow the fuse
