Subject Topic: Carver water heater instructions
Page:  1  2 Post Reply Post New Topic
PersonColin21
27/7/2020 at 3:30pm
 Location: East Herts
 Outfit: 1992 Elddis Wisp 450CT + X Trail View Colin21's Profile View Profile   Reply to Colin21 Reply   Quote Colin21 Quote
Joined: 05/11/2013

Diamond Member
Diamond Member

Forum Posts:   6270
Site Reviews Total: 18
Site Reviews 2024: 1
Site Reviews 2023: 1
Site Reviews 2022: 2
Site Reviews 2021: 2
Site Reviews 2020: 0
Site Reviews 2019: 2
Site Reviews 2018: 3
Site Nights 2024: 7
Site Nights 2023: 8
Site Nights 2022: 12
Site Nights 2021: 18
Site Nights 2020: 0
Site Nights 2019: 21
Site Nights 2018: 18
Quote: Originally posted by BOINGFC on 27/7/2020
Hi I have just bought an Elddis Autostratus Motor home, which has the Carver Cascade 2 Water Heater, I'm really struggling to locate the problem, no lights come on the control panel at all, either when Leisure battery or hooked up to the mains, My Volt meter confirmed that 12v power from the Leisure battery was getting to the panel, but still not lights, cant work out what i am missing.

Gas is on as my cooker works, water pump is working as tap run water.

any help greatly appreciated


That sounds very much like a blown fuse. The carver heater controls work off 12 volts, so there is probably a fuse somewhere that feeds it. If I remember right there is a fuse inside the control box on the one in my caravan, so if yours is a small box like mine it will have a fuse inside it too.

Mine looks like this;






Post last edited on 27/07/2020 15:42:02

-------------
Best Regards,
Colin


PersonBOINGFC
27/7/2020 at 3:51pm
 Location: West Midlands
 Outfit: Elldis Autostratus 2.5l TD View BOINGFC's Profile View Profile   Reply to BOINGFC Reply   Quote BOINGFC Quote
Joined: 27/7/2020

Standard Member
Standard Member

Forum Posts:   12
Site Reviews Total: 1
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 0
Site Reviews 2021: 0
Site Reviews 2020: 1
Site Reviews 2019: 0
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 0
Site Nights 2021: 0
Site Nights 2020: 5
Site Nights 2019: 0
Site Nights 2018: 0
Thanks Colin, Mine is like this

https://www.bing.com/images/search?view=detailV2&ccid=xGN36k4F&id=35C8BB7149785081........


There is a fuse on the wire which serves 12v but it is not blown, and the control panel is getting 12v


PersonColin21
27/7/2020 at 4:11pm
 Location: East Herts
 Outfit: 1992 Elddis Wisp 450CT + X Trail View Colin21's Profile View Profile   Reply to Colin21 Reply   Quote Colin21 Quote
Joined: 05/11/2013

Diamond Member
Diamond Member

Forum Posts:   6270
Site Reviews Total: 18
Site Reviews 2024: 1
Site Reviews 2023: 1
Site Reviews 2022: 2
Site Reviews 2021: 2
Site Reviews 2020: 0
Site Reviews 2019: 2
Site Reviews 2018: 3
Site Nights 2024: 7
Site Nights 2023: 8
Site Nights 2022: 12
Site Nights 2021: 18
Site Nights 2020: 0
Site Nights 2019: 21
Site Nights 2018: 18
Strange that there's no lights on if the control box is getting 12 volts. Is the earth connection to the box ok? That box just looks like a slightly later version to the one I have.

If there are fuses inside the box, like mine, have you tried just removing them and putting them back, as sometimes the tiniest bit of corrosion that you can't even see will stop them making contact properly.



-------------
Best Regards,
Colin


PersonBOINGFC
27/7/2020 at 4:37pm
 Location: West Midlands
 Outfit: Elldis Autostratus 2.5l TD View BOINGFC's Profile View Profile   Reply to BOINGFC Reply   Quote BOINGFC Quote
Joined: 27/7/2020

Standard Member
Standard Member

Forum Posts:   12
Site Reviews Total: 1
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 0
Site Reviews 2021: 0
Site Reviews 2020: 1
Site Reviews 2019: 0
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 0
Site Nights 2021: 0
Site Nights 2020: 5
Site Nights 2019: 0
Site Nights 2018: 0
there is no fuse inside the unit, and it all looks well connected and very clean, so im not quite sure where to go next


PersonColin21
27/7/2020 at 4:58pm
 Location: East Herts
 Outfit: 1992 Elddis Wisp 450CT + X Trail View Colin21's Profile View Profile   Reply to Colin21 Reply   Quote Colin21 Quote
Joined: 05/11/2013

Diamond Member
Diamond Member

Forum Posts:   6270
Site Reviews Total: 18
Site Reviews 2024: 1
Site Reviews 2023: 1
Site Reviews 2022: 2
Site Reviews 2021: 2
Site Reviews 2020: 0
Site Reviews 2019: 2
Site Reviews 2018: 3
Site Nights 2024: 7
Site Nights 2023: 8
Site Nights 2022: 12
Site Nights 2021: 18
Site Nights 2020: 0
Site Nights 2019: 21
Site Nights 2018: 18
I must admit I'm stumped too without actually being there to look at it. Can you get to the heater unit itself to check if it's getting any power? Still seems strange there's no lights on though. Maybe a fault actually inside the control box, or a faulty light. I would imagine they are probably LEDs.



-------------
Best Regards,
Colin


Advertisement



PersonBOINGFC
28/7/2020 at 9:40am
 Location: West Midlands
 Outfit: Elldis Autostratus 2.5l TD View BOINGFC's Profile View Profile   Reply to BOINGFC Reply   Quote BOINGFC Quote
Joined: 27/7/2020

Standard Member
Standard Member

Forum Posts:   12
Site Reviews Total: 1
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 0
Site Reviews 2021: 0
Site Reviews 2020: 1
Site Reviews 2019: 0
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 0
Site Nights 2021: 0
Site Nights 2020: 5
Site Nights 2019: 0
Site Nights 2018: 0
I can see the front of the heater, there is a cover i removed which exposes the elements, wiring as the red reset switch (I think) does 240v or 12v power this Heater at this point? I've also seen some videos showing a control unit which is located behind the cowel, and accesbile from outside the van, but ive not gon as far as dismatling the outside as yet


Personmarg6
28/7/2020 at 10:06am
 Location:
 Outfit:  View marg6's Profile View Profile   Reply to marg6 Reply   Quote marg6 Quote
Joined: 11/8/2016

Diamond Member
Diamond Member

Forum Posts:   3126
Site Reviews Total: 3
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 0
Site Reviews 2021: 0
Site Reviews 2020: 0
Site Reviews 2019: 3
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 0
Site Nights 2021: 0
Site Nights 2020: 0
Site Nights 2019: 15
Site Nights 2018: 0
gary at arc systems when we had trouble with ours told me to reach down the back of the fire, and with my left hand feel down the back about 2/3rds up there should be an indentation from memory (this was about 15 yrs ago) and to press that area, and sure enough even tho i couldnt feel anything myself but doing so the heating would start working again! have a try, hopefully it solves your issue failing that you may have to ring gary, he has been brilliant with many members on here over the years


PersonColin21
28/7/2020 at 11:31am
 Location: East Herts
 Outfit: 1992 Elddis Wisp 450CT + X Trail View Colin21's Profile View Profile   Reply to Colin21 Reply   Quote Colin21 Quote
Joined: 05/11/2013

Diamond Member
Diamond Member

Forum Posts:   6270
Site Reviews Total: 18
Site Reviews 2024: 1
Site Reviews 2023: 1
Site Reviews 2022: 2
Site Reviews 2021: 2
Site Reviews 2020: 0
Site Reviews 2019: 2
Site Reviews 2018: 3
Site Nights 2024: 7
Site Nights 2023: 8
Site Nights 2022: 12
Site Nights 2021: 18
Site Nights 2020: 0
Site Nights 2019: 21
Site Nights 2018: 18
Yes Gary is the expert in these matters.

The actual controls for the gas heating are all operated by 12 volts, but if you have the optional electric element that will be mains. Ours is gas only, but slightly later ones were gas or electric. The two systems are completely separate, so it may be that the unit will function on electric but not gas. It certainly won't work on gas if that small control box won't light up.


-------------
Best Regards,
Colin


PersonBOINGFC
28/7/2020 at 3:12pm
 Location: West Midlands
 Outfit: Elldis Autostratus 2.5l TD View BOINGFC's Profile View Profile   Reply to BOINGFC Reply   Quote BOINGFC Quote
Joined: 27/7/2020

Standard Member
Standard Member

Forum Posts:   12
Site Reviews Total: 1
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 0
Site Reviews 2021: 0
Site Reviews 2020: 1
Site Reviews 2019: 0
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 0
Site Nights 2021: 0
Site Nights 2020: 5
Site Nights 2019: 0
Site Nights 2018: 0
Just spoke to Gary at Arc Systems who is sending me a new Cascade Rapide 2 switch, fingers crossed this is the issue.

Thanks All


PersonColin21
28/7/2020 at 3:40pm
 Location: East Herts
 Outfit: 1992 Elddis Wisp 450CT + X Trail View Colin21's Profile View Profile   Reply to Colin21 Reply   Quote Colin21 Quote
Joined: 05/11/2013

Diamond Member
Diamond Member

Forum Posts:   6270
Site Reviews Total: 18
Site Reviews 2024: 1
Site Reviews 2023: 1
Site Reviews 2022: 2
Site Reviews 2021: 2
Site Reviews 2020: 0
Site Reviews 2019: 2
Site Reviews 2018: 3
Site Nights 2024: 7
Site Nights 2023: 8
Site Nights 2022: 12
Site Nights 2021: 18
Site Nights 2020: 0
Site Nights 2019: 21
Site Nights 2018: 18
Quote: Originally posted by BOINGFC on 28/7/2020
Just spoke to Gary at Arc Systems who is sending me a new Cascade Rapide 2 switch, fingers crossed this is the issue.

Thanks All


I did suspect it may be a faulty control box, as power was getting to it but no lights were coming on. I hope that does the trick. Let us know how you get on.


-------------
Best Regards,
Colin


Advertisement



PersonDickie123
via mobile 29/12/2021 at 10:34am
 Location:
 Outfit: None Entered View Dickie123's Profile View Profile   Reply to Dickie123 Reply   Quote Dickie123 Quote
Joined: 29/12/2021

Standard Member
Standard Member

Forum Posts:   1
Site Reviews Total: 0
Site Reviews 2024: 0
Site Reviews 2023: 0
Site Reviews 2022: 0
Site Reviews 2021: 0
Site Reviews 2020: 0
Site Reviews 2019: 0
Site Reviews 2018: 0
Site Nights 2024: 0
Site Nights 2023: 0
Site Nights 2022: 0
Site Nights 2021: 0
Site Nights 2020: 0
Site Nights 2019: 0
Site Nights 2018: 0
We have a very old Luna caravan (1996) with a cascade 2 water heater fitted. We are able to get hot water on 240v but unable to get any hot water from gas !!! Any suggestions welcome 🙏 thanks


PersonFiona W
via mobile 29/12/2021 at 5:35pm
 Location: Ayrshire
 Outfit: Auto-Sleeper MHs View Fiona W's Profile View Profile   Reply to Fiona W Reply   Quote Fiona W Quote
Joined: 10/4/2007

Diamond Member
Diamond Member

Forum Posts:   5144
Tent Reviews:   1
Site Reviews Total: 234
Site Reviews 2024: 18
Site Reviews 2023: 8
Site Reviews 2022: 12
Site Reviews 2021: 10
Site Reviews 2020: 4
Site Reviews 2019: 9
Site Reviews 2018: 18
Site Nights 2024: 37
Site Nights 2023: 25
Site Nights 2022: 32
Site Nights 2021: 25
Site Nights 2020: 20
Site Nights 2019: 28
Site Nights 2018: 30
Welcome to UKCS, Dickie123. That happened to our heater in a MH that was 10 years old when we got it. The habitation service revealed that the gas burner component was corroded & goosed. (Whiff of gas outside.) We were unable to replace the part (we didnt know about arc systems then), though you may be able to.
It didnt matter - we mostly stayed on sites with EHU as the fridge didnt work on gas either (that was corroded too).
Edit because it may be a cold temperature problem… I can’t remember the gas types to say which ones stop in the cold.

-------------
2024 = 20 sites / 41 nights. 2023 = 9/23. 2022 = 13/35. 2021 = 11/29. 2020 = 4/20. 2019 = 13/35. 2018 = 20/33. 2017 = 10/22. 2016 = 19/33. 2015 = 15 sites / 27 nights. Didn't count 1976 to 2014.


PersonColin21
29/12/2021 at 6:09pm
 Location: East Herts
 Outfit: 1992 Elddis Wisp 450CT + X Trail View Colin21's Profile View Profile   Reply to Colin21 Reply   Quote Colin21 Quote
Joined: 05/11/2013

Diamond Member
Diamond Member

Forum Posts:   6270
Site Reviews Total: 18
Site Reviews 2024: 1
Site Reviews 2023: 1
Site Reviews 2022: 2
Site Reviews 2021: 2
Site Reviews 2020: 0
Site Reviews 2019: 2
Site Reviews 2018: 3
Site Nights 2024: 7
Site Nights 2023: 8
Site Nights 2022: 12
Site Nights 2021: 18
Site Nights 2020: 0
Site Nights 2019: 21
Site Nights 2018: 18
Quote: Originally posted by Fiona W on 29/12/2021
Welcome to UKCS, Dickie123. That happened to our heater in a MH that was 10 years old when we got it. The habitation service revealed that the gas burner component was corroded & goosed. (Whiff of gas outside.) We were unable to replace the part (we didnt know about arc systems then), though you may be able to.
It didnt matter - we mostly stayed on sites with EHU as the fridge didnt work on gas either (that was corroded too).
Edit because it may be a cold temperature problem… I can’t remember the gas types to say which ones stop in the cold.


Butane (Calor blue cylinder) won't work very well in the cold but Propane (Calor red cylinder) is fine. We have always found that even Butane will be ok down to about 5C anyway. Not a problem for us as we are never away in the caravan when the temperature gets anywhere near that low.

Our Carver Cascade 2 "exploded" last year. Not the gas, but the water. The through rod corroded and apparently, as I wasn't in the van at the time, it went off with quite a bang and water went everywhere. As I had only just turned it on I would imagine it was pressure from the heating water that did it. We only go on sites with electric supply because of our fridge, so I have now replaced the Carver with a new Propex electric water heater, which turned out to be £100 cheaper than getting the Carver repaired.



-------------
Best Regards,
Colin
